ELECTRIC PLATFORM TRUCK
 TECHNICAL DATA
| Width and Length of the frame |
700 mm x 1725 mm |
| Effective Platform Length |
1000 mm or more |
| Min. axle width for right angle turn |
1500 mm |
| Turning Radius |
2100 mm |
| Capacity |
500 Kgs |
| Drive Motor |
0.8 KW or more |
| Travel Speed |
Laden: 10 Km/hr Unladen: 15 Km/hr |
| Gradeability |
Laden: 18% Unladen: 05% |
| Battery |
24 V (12 V x 2), 185 AH/5H |
| Wheels (Solid Rubber) |
250 mm x 100 mm |
FEATURES
Ergonic construction for steering comfort and easy serviceability.
Stable, articulated type steering axle top ensures constant road grip.
Easily accessible bake pedal.
Double platform for optimum utilization when transporting light goods.
Electronically controlled speed for step less regulation to the desired speed level.
Excellent maneuverability at all speeds.
All control positioned close to each other on the handle to enable easy fingertip operation.
Chain drive for motor to the drive wheels.
Emergency and parking break.
Simultaneous supply cut off to the motor through micro switch to ensure safety.
Light and strong frame.
Rubber bumper in front.
Ladder on the left side of the drivers platform to enable the operator to pick from shelves up to 2.5 mtr high from the floor.
We will provide battery indicator.
|
